Waterproof cable connector installation process and production company information introduction

Waterproof cable joint installation process

Make the connecting tube and wrap it with a yellow ribbon. The overlapping width is half of the bandwidth. The winding length is more than 150~200mm. The number of layers depends on the voltage level. Then the outer layer is wrapped with J-20 self-adhesive tape, and the overlap is half the bandwidth. The length should be at least 100-150mm over the yellow ribbon, and the number of layers is not less than 6 layers.

After the three phases are completed. They are rounded, and then wound into a circular shape by self-adhesive tape as described above, and finally wound with a plastic anti-wear tape, the overlapping amplitude is half of the bandwidth, and the overlapping amplitude is half of the bandwidth. The length should exceed the self-adhesive tape by at least 150mm and the number of layers should be no less than 3 layers.

Production company information introduction

YUEQING JIXIANG CONNECTOR CO.,LTD In order to create a better brand image, JIXAING is based on honesty, maintains innovation through development, and fully implements quality service. The company's products are widely used in electronics, machinery, equipment, electrical and other industrial fields. They are also certified to CE, IP68, ROHS, EX, ATEX, TUV and ISO9001.
